M19 IP67 Power Connector Multiple 5 Pin Socket Connector Waterproof RoHS

Place of Origin	Guangdong, China
Brand Name	SHANGWEN
Model Number	SW19-5JSZ
Minimum Order Quantity	2 pieces
Price	$2.20/pieces 2-99 pieces
Packaging Details	10pcs/sample bag<br>25pcs/Blister box(23cm x 23cm)<br>500pcs/carton (51cm x 26cm x 34cm)

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Features	Quick, Simple Self Locking System	Name	M19 IP67 Power Connector
Application	Industrial	Multiple Cores	2,3,4,5,6,9,3+9 Pin Support
Type	SW19 Self-locking Series	Gender	Male Socket
Industrial Electronics	Accessories
Highlight	RoHS IP67 Power Connector , IP67 Power Connector Multiple , 5 Pin Socket Connector Waterproof

Leave a Message

Product Description

Rohs Ce M19 Series Waterproof Rating Ip67 Industrial 5 Pin Male Socket Connector

Products Description

SW19 Self-locking series-5 Pin connector

M19 series is an industrial connector, which includes male plug, female plug and male socket.

The cable skin is molded by a plastic wrap mold. All materials comply with environmental RoHS standards, and passed CE,UL,FCC and other multinational certification. Male coordinate with waterproof apron, the waterproof grade of the connector up to IP67.

☑Adopt one key press button locking method,plug and play,fast and convenient;
☑Precision waterproof design,with high waterproof level,no fear of wading environment;
☑Adopt high-strength structural materials, pressure-resistant structure design,can
withstand greater vibration and shock.
☑High-power industrial waterproof connector - waterproof, moisture-proof and dust proof

There are two locking methods:

1. Push-pull self-locking connection

2. Plastic screw connection, both locking design is very reliable.

The material selection of the inner core uses gold-plated pin, which is conducive to the stable passage of the current. A variety of cores can be selected, making its application field more extensive.

1. Electrical parameters

Contacts NO.	5 pin
Rated current	20A
Rated voltage	300V AC
Withstand voltage	1500V
Insulation resistance	≥100mΩ
Contact resistance	≤10mΩ

2. Mechanical parameters

Service life	＞1000 times
Power line	Φ4.5mm-Φ11mm
Cable size	0.3mm²-2.5mm²(22AWG-12AWG)
Type of terminals	Screw terminal and soldering terminal available

3. Material and environmental parameters

Shell	High performance engineering plastics
Contacts	Copper alloy
Contact diameter	Φ2.4mm
Protection degree	IP67
Flame-retardant grade	UL94-V0
Temperature range	-40℃~105℃
