M19 waterproof Connector Self Locking Industrial Female Connector 3+9 PinSignal power integrated

Place of Origin Guangdong, China
Brand Name SHANGWEN
Model Number SW19-12KSFT
Minimum Order Quantity 2 pieces
Price $2.20/pieces 2-99 pieces
Packaging Details 10pcs/sample bag<br>25pcs/Blister box(23cm x 23cm)<br>500pcs/carton (51cm x 26cm x 34cm)

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Push-pull Self-locking Connection Name Waterproof M19 Connector
Type SW19 Self-locking Series Gender Female
Industrial Electronics Accessories Application Industrial
Multiple Cores 2,3,4,5,6,9,3+9 Pin Support
Highlight

Outdoor M19 Connector

,

M19 Connector Self Locking

,

Industrial Small Female Connector

Leave a Message
Product Description



Outdoor Quick Simple Self Locking System 3 Core 9 Pin Industrial Female Connector





Model: SW19-12KSFT (3+9 pin female plug)



☑Small size of product

☑ Contact pin: Screw cable,soldering cup and crimp available

☑ Assembly: wire to wire type(no cable),wire to wire by overmolding, wire to board

☑ Black,blue,white and yellow color supported

☑ Different cable length could be customized
☑Multiple cores -2,3,4,5,6,9,3+9 pin support multiple application scenarios

☑Quick, simple self locking system
☑Connect reliably

☑ Advanced structure: Self-locking





Products Description
SW19 Self-locking series-3+9 Pin connector



1. Electrical parameters

Contacts NO.
3+9 pin
Rated current
5A
Rated voltage
60V AC
Withstand voltage
125V
Insulation resistance
≥100mΩ
Contact resistance
≤10mΩ
2. Mechanical parameters
Service life
>1000 times
Power line
Φ4.5mm-Φ11mm
Cable size
0.3mm²-2.5mm²(22AWG-12AWG)
Type of terminals
Screw terminal and soldering terminal available
3. Material and environmental parameters
Shell&insulated parts
High performance engineering plastics
Contacts
Copper alloy
Contact diameter
Φ1.0mm
Protection degree
IP67
Flame-retardant grade
UL94-V0
Temperature range
-40℃~105℃
