Male Chassis Waterproof Power Connector 250V 20A 3 Conductor

Place of Origin China
Brand Name Shang Wen
Certification Rohs UL
Model Number SW3MPX
Minimum Order Quantity 100pcs
Price Negotiable
Packaging Details Internal blister box 23x23cm External carton 51x26x34cm
Delivery Time 5-8 working days
Payment Terms T/T
Supply Ability 100000+pcs+per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Waterproof Power Connector 250V Contacts 3pin
Application For Power Connection Gender Male/Power-in
Conductor Material Cu Alloy Shell Material Polyamide
Type Of Terminals 3/16" Flat Tab Connecting Mode Fast Rotating Connection
IP Grade IP65
Highlight

250V Waterproof Power Connector

,

Waterproof Power Connector 20A

,

Male Chassis Power Connector

Leave a Message
Product Description

IP65 Waterproof Powercon Male Chassis 3 Conductor 20A 250V Power-In 3/16" Flat Tab Terminals For Led Screen



SW3MPX is widely used in outdoor LED display power connection.

With the continuous development of the entertainment industry, the demand for products with connected systems is also increasing.
The sealed connector that can be adapted for outdoor use came into being.
To this end, Shangwen has developed a new series of outdoor connectors, which includes power connectors, signal connectors and audio connectors. These rugged, sealed connectors are IP65 rated for outdoor protection.
The shell part is made of PA6 material, with stable electrical performance, good pressure resistance, high temperature resistance, explosion resistance and corrosion resistance.
The contact part is made of beryllium copper material imported from the US and plated with silver, which has strong contact stability and can strengthen the control of temperature rise.



Using rotary locking design, easy to operate, stable and reliable !

Male Chassis Waterproof Power Connector 250V 20A 3 Conductor 0



Product features

Connect reliably
Small size of product
☑ Three connect methods:male plug to female plug,male plug to female chassis,female plug to male chassis
High current capacity,rated at 20A/250V AC
Color coded for easy identification,powercon offers power-in(blue) and power-out(white) versions with different keying to avoid the possibility of intermating
Waterproof grade IP65
 Secure,quick, simple locking system
 Lockable 3 conductor equipment(AC) connector with contacts for line,neutral and pre-mating ground



Technical parameters

- Electrical parameters

Contacts No.               3
Rated current20A
Rated voltage250V AC
Contact resistance≤5mΩ
Dielectric strength

4000V DC

Insulation resistance

>1000MΩ

- Mechanical parameters

Service life>1000 times
Power line2.5mm²(8mm-12mm)
Wire stripping length7-8mm
Type of terminals3/16'' flat tab/solder termination

-Material and environmental parameters

Shell PA
ConductorCu alloy
Conductor surfaceAg
Flame-retardant gradeUL94-V0
Temperature range-30°C~+80°C
IP gradeIP65

Product Profile
