Ruggedized Ethernet Chassis Connector Lockable IP65 RJ45 Connector
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | For Signal Connection | Gender | Male |
|---|---|---|---|
| Shell Material | Zinc Die-cast | Shell Plating | Pearl Chromium |
| Color | Silver Shell/Yellow Boot | IP Grade | IP65 |
| Name | Ethernet Chassis Connector | Feature | Waterproof |
| Highlight | Ruggedized Ethernet Chassis Connector,Ethernet Chassis Connector Lockable,IP65 RJ45 Connector |
||
Product Description
Outdoor Use Waterproof IP65 Ethercon Signal Plug RJ45 Port Yellow Boot For Led Screen Audio Video Lighting Applications
SW8MC-B-2 is widely used in outdoor rental LED display/Audio/Video/Lighting signal connection
The shell part is made of zinc alloy material,is a very ruggedized and lockable RJ45 connector system.This material can cope with a variety of harsh application environments.
The shell is plated of pearl cr, the exterior is matte in texture.
This connector is made up of a shell, clip and boot. The boot is suitable for cable diameters from 5-8mm network cables.It does not include a RJ45 plug.
Using pull and out locking design, easy to operate, stable and reliable !
Product features
☑ The RJ45 system for harsh and demanding environment
☑ Cable connector carrier accepts the most common RJ45 plugs
☑ Rugged diecast shell and unique chuck type strain relief
☑ Protects Ethernet connections in a variety of commercial type applications and is designed to prevent breakage of the fragile components of standard RJ45 connectors
☑ Allows assembly of non pre-assembled conventional RJ45 cables
☑ IP65 waterproof grade
☑ All sockets are equipped with waterproof gaskets. With the installation of gaskets, the protection grade of IP65 can be reached,
which can fully meet the durable and stable signal transmission under harsh outdoor conditions
☑ The back-end can be flexibly modified according to actual requirements
☑ The transmission grade reaches CAT5e and is compatible with transmission grades below 5E
☑ With shielding function
Technical parameters
Mechanical parameters
| Service life | ＞1000 times |
| Network line | 5-8mm |
| Insertion force | ≤20N |
| Locking device | Latch lock |
Material and environmental parameters
| Shell | Zinc diecast |
| Boot | Polyamide |
| Shell plating | Pearl chromium |
| Temperature range | -30°C~+80°C |
| IP grade | IP65 |
Product Profile
Packing
FAQ
1. Why do we choose SHANG WEN supply?
A:We promise:All of our products are power regulated.The output voltage and current are true one.all with good quality and competitive price.We assure you timely delivery by keeping 80% standard products inventory and best after-sale service.All have done 100% long time ful-load aging test/ burn-in test before shipment.
2. What is the applicable range of this product?
A:Suitable for fixed & rental installation display screen, stage lighting and sound, security, new energy, medical etc.
3. Can your products pass CE/ROHS certificate?
A:Yes,our products meet the industrial standards,like:CE/UL/RoHS/CQC.
4. Accept sample order ?What is your minimum order quantity?
A:Trial order or sample order is accept,but same cost as bulk.
5. What are the shipping ways you can offer?
A: By air/sea according to customers'requirements.
6. Do your products come with warranty?
A:Yes,we promise 1-3 year warranty according to different model.
