Stable XLR Connector Corrosion Resistant 3 Pin Cable Connectors Electrical
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Audio Transmission | Gender | Male |
|---|---|---|---|
| Shell Material | Zinc Die-cast | Shell Plating | Chromium |
| Color | Black Shell/ Colored Boot | IP Grade | IP40 |
| Feature | Waterproof IP65 | Wire Diameter Range | 5-8mm |
| Highlight | Stable XLR Connector,XLR Connector Corrosion Resistant,3 Pin Cable Connectors Electrical |
||
Product Description
Indoor Use Ip40 3pin Xlr Male Plug Connector Black Metal Housing Gold Plated core For Audio Video Lighting Application
SWM3X-TB is widely used in indoor Audio Transmission scenarios.
Introducing the 3-pole male cable connector with a sleek black metal housing and gold contacts, the globally recognized standard for XLR cable connectors. This series boasts a range of enhanced features that ensure stability, ease of assembly, improved contact integrity, and superior cable strain relief.The gold contacts offer superior conductivity and signal integrity, allowing for optimal audio transmission with minimal signal loss or distortion. These contacts ensure a high-quality audio experience, making them ideal for professional audio applications.
Notable improvements in this series include enhanced stability during assembly, simplifying the installation process and reducing the risk of misalignment or disconnection. Additionally, the contact integrity is improved, ensuring a secure and uninterrupted signal flow.
Furthermore, the cable strain relief feature alleviates stress on the cable, protecting it from damage and ensuring a longer lifespan. This innovative design safeguards against accidental pulls or twists, providing added reliability and longevity to the connector and cable.
Improved chuck strain relief,increased retention and easier and faster assembly and operation!
Product features
☑Stainless steel housing provides durability, corrosion-resistant with long service life more than 1000 times and high reliability suitable for harsh environment
☑Boot with TPU gland gives high protection to cable bending stresses
☑Colored rings and boots available for coding or identification
☑Standard cable clamps are available for different wire diameters
☑Contact available with 3-7 poles in gold or silver plated contacts
☑Internal thread on shell is well protected against any damage
Technical parameters
-Electrical parameters
|
Capacitance between contacts |
≤4pF |
|
Contact resistance |
≤3mΩ |
|
Dielectric strength |
1.5kVdc |
|
Insulation resistance |
> 1.5GΩ (initial) |
|
Rated current per contact |
10A |
|
Rated voltage |
<50V |
Mechanical parameters
| Service life | ＞1000 times |
|
Wire |
3.5-8mm |
| Insertion force | ≤40N |
|
Withdrawal force |
≤40N |
| Locking device | Latch lock |
Material and environmental parameters
|
Contacts |
Cu alloy |
|
Contact plating |
Au |
|
Strain relief |
Polyacetal (POM) |
|
Insert |
Polyamide (PA 66 +30 % GF) |
| Shell | Zinc diecast |
| Boot | TPU |
| Shell plating | Chromium |
| Temperature range | -20°C~+80°C |
|
Flame-retardant grade |
UL 94 HB |
| IP grade | IP40 |
Product Profile
Packing
FAQ
1.Why do we choose SHANG WEN supply?
A:We promise:All of our products are power regulated.The output voltage and current are true one.all with good quality and competitive price.We assure you timely delivery by keeping 80% standard products inventory and best after-sale service.All have done 100% long time ful-load aging test/ burn-in test before shipment.
2.What is the applicable range of this product?
A:Suitable for fixed & rental installation display screen, stage lighting and sound, security, new energy, medical etc.
3.Can your products pass CE/ROHS certificate?
A:Yes,our products meet the industrial standards,like:CE/UL/RoHS/CQC.
4.Accept sample order ?What is your minimum order quantity?
A:Trial order or sample order is accept,but same cost as bulk.
5.What are the shipping ways you can offer?
A:By air/sea according to customers'requirements.
6.Do your products come with warranty?
A:Yes,we promise 1-3 year warranty according to different model.
